General specifications

Operating system

Windows 10 and higher macOS 11 (BigSur) and higher
Android v11 and higher (ClickShare App)
iOS 14 and higher (ClickShare App)

System requirements

For a smooth experience with Microsoft Teams or Zoom
Minimum: Intel i3 dual-core processor or AMD Ryzen 7 / 8GB RAM / OS: Windows 10 latest build or Mac OS Mojave latest build
Recommended: Intel i5 4-core processor or AMD Ryzen 9 / 8GB RAM / OS: Windows 11 latest build or Mac OS latest build

Video outputs

4K UHD (3840*2160) @ 30Hz. HDMI™ 1.4b or USB-C DisplayPort 1.2 (only Gen2)

Audio output

USB, HDMI

USB

1 X USB-A, 1 X USB-C

ClickShare Buttons

1

ClickShare App

Desktop & Mobile

Native protocols

Airplay, Google Cast, Miracast

Maximum sources simultaneously on screen

1

Noise Level

Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C

Authentication protocol

WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode

Wireless transmission protocol

IEEE 802.11 a/g/n/ac and IEEE 802.15.1

Reach

Max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS)

Frequency band

2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)

Connections

1x Ethernet LAN 1Gbit
1x USB-C 2.0 (front); 1x USB-A 2.0 (front) – only Gen2: 1x USB-C 3.0 (front); 1x USB-A 3.0 (front)

Temperature range

Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)

Humidity

Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing

Anti-theft system

Kensington lock

Certifications

FCC/CE

Touch screen support & Interactivity

/

Wireless conferencing

via App or Button

Local view

Local view of the room display only

Network connection

LAN & WiFi

Management and reporting

Yes

Warranty

1 year standard. 5 years coverage upon registering via SmartCare

ClickShare Base Unit dimensions

Dimensions (HxWxD)

34 mm x 135 mm x 135 mm

Power consumption

Operational: 5-10W, 24W Max

Power supply

Standard 110/220 V AC plug or USB-C (only Gen2)

Weight

900 gr
