| Projector type |
LCD projectors |
| LCD panel |
|
| Panel size |
19.3 mm (0.76 in) diagonal (16:10 aspect ratio) |
| Pixels |
2,304,000 (1920 x 1200) pixels x 3 |
| Light source |
Laser diodes |
| Light output1
?
|
8,200 lm2 / 8,200 lm (ANSI)3 |
7,500 lm2 / 7,500 lm (ANSI)3 |
Time until
light output
declines to 50 %4 |
20,000 hours (NORMAL/QUIET), 24,000 hours (ECO) |
| Resolution |
WUXGA (1920 x 1200 pixels) |
| Contrast ratio2 |
3,000,000:1 (Full On/Full Off)
(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1] or [2]. HDMI™ signal input) |
| Screen size (diagonal) |
1.02–10.16 m (40–400 in), 1.52–10.16 m (60–400 in) with the ET-ELW22,
2.54–10.16 m (100–400 in) with the ET-ELU20, 16:10 aspect ratio |
Center-to-corner
zone ratio2 |
85 % |
| Lens |
Powered zoom (throw ratio 1.61–2.76:1), powered focus F = 1.7–2.3,
f = 26.8–45.5 mm (for supplied lens; optional lenses also available) |
Lens shift
(From the origin point
of the lens mounter) |
|
| Vertical |
±67 % (powered), ±60 % (with ET-ELW22), ±50 % (with ET-ELU20) |
| Horizontal |
±35 % (powered), ±30 % (with ET-ELW22), ±24 % (with ET-ELU20) |
| Keystone correction range |
Vertical: ±25 ° (±22 ° with ET-ELW21/ET-ELW22),(±5 ° with ET-ELU20)
Horizontal: ±30 ° (±15 ° with ET-ELW21/ET-ELW22), (0 ° with ET-ELU20) |
| Installation |
Ceiling/floor, front/rear, free 360-degree installation |
| Terminals |
|
| HDMI™ IN |
HDMI™ x 3 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input5), CEC supported |
| COMPUTER IN |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| MONITOR OUT |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
SERIAL/MULTI
SYNC IN |
D-sub 9-pin (female) x 1 for external control/link control (RS-232C compliant) |
| MULTI SYNC OUT |
D-sub 9-pin (male) x 1 for link control |
| REMOTE 1 IN |
M3 stereo mini-jack x 1 for wired remote control |
| REMOTE 2 IN |
D-sub 9-pin (female) x 1 for external control (parallel) |
| AUDIO IN |
M3 stereo mini-jack x 1 |
| AUDIO OUT |
M3 stereo mini-jack x 1 |
| DIGITAL LINK/LAN |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control)
(HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2],
Art-Net, HDCP 2.3, Deep Color, 4K/60p5, 6 signal input) |
| LAN |
RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net) |
| DC OUT |
USB Type A x 1 (for power supply, DC 5 V, 2 A) |
| Power supply |
AC 100–240 V, 50 Hz/60 Hz |
| Maximum power consumption7 |
465 W (5.0–2.0 A) (475 VA)
(Power consumption is 445 W at AC 200–240 V) |
435 W (4.7–1.9 A) (445 VA)
(Power consumption is 415 W at AC 200–240 V) |
| On-mode power consumption (Operating mode)7 |
- [NORMAL]
- 415 W (AC 100–120 V),
395 W (AC 200–240 V)
- [ECO]
- 295 W (AC 100–120 V),
285 W (AC 200–240 V)
- [QUIET]
- 290 W (AC 100–120 V),
280 W (AC 200–240 V)
|
- [NORMAL]
- 385 W (AC 100–120 V),
365 W (AC 200–240 V)
- [ECO]
- 275 W (AC 100–120 V),
265 W (AC 200–240 V)
- [QUIET]
- 275 W (AC 100–120 V),
265 W (AC 200–240 V)
|
| Filter |
Included (Estimated maintenance time: approx. 20,000 hours) |
| Operation noise2 |
34 dB (NORMAL/ECO), 26 dB (QUIET) |
32 dB (NORMAL/ECO), 26 dB (QUIET) |
Dimensions
(W x H x D) |
561 x 224 x 439 mm (22 3/32˝ x 8 13/16˝ x 17 9/32˝ ) (With legs at shortest position, including lens and protruding parts) |
| Weight8 |
Approx. 18.6 kg (41.0 lbs) (with supplied lens) |
| Operating environment |
Operating temperature: 0–45 °C (32–113 °F)9, operating humidity: 20–80 % (no condensation) |
| Applicable software |
Logo Transfer Software, Multi Monitoring & Control Software, Projector Network Setup Software, Smart Projector Control for iOS/Android™, Geometry Manager Pro10 |
