Samaung -130 inch active Led
0- Category:VIDEOWALL PANEL DISPLAY
IAC, Indoor LED- All in One
LH015IACCHS/XL
- Discover a True All-in-One LED Display, experience easier installation than ever with Samsung’s exclusive Quick Build technology
- Support for various installation scenarios through flexible design
- LED HDR technology for clear, accurate picture presentation
Specification
| Specification | Details |
|---|---|
| Display Type | All-in-One Indoor LED Display |
| Screen Size | 130 Inch |
| Pixel Pitch | 1.5 mm |
| Resolution | 1920 × 1080 (Full HD) |
| Pixel Configuration | RGB (1 Red, 1 Green, 1 Blue) |
| LED Type | SMD (3-in-1 LED) |
| Brightness | 1,000 nits (Peak) / 500 nits (Max) |
| Contrast Ratio | 6,000:1 |
| Viewing Angle | 160° (H) / 160° (V) |
| Refresh Rate | 3,840 Hz |
| Visual Refresh Rate | 7,680 Hz |
| Bit Depth | 16-bit (20-bit internal processing) |
| HDR Support | LED HDR / AI Picture |
| Color Temperature | 6,500K ± 500K (Adjustable 2,800K – 10,000K) |
| Dimensions (W × H × D) | 2888.5 × 1628.5 × 56.2 mm |
| Total Depth with Wall Mount | 62.2 mm |
| Screen Weight | 125 kg |
| Modules Configuration | 12 × 9 |
| Input Voltage | 100 – 240V AC |
| Power Frequency | 50 / 60 Hz |
| Power Consumption (Max) | 1700 W per screen |
| Power Consumption (Typical) | 685 W per screen |
| Heat Generation (Max) | 5800 BTU |
| Operating Temperature | 0°C – 40°C |
| Operating Humidity | 10% – 80% RH |
| Storage Temperature | -20°C – 45°C |
| Storage Humidity | 5% – 95% RH |
| IP Rating | IP20 |
| LED Lifetime | Up to 100,000 hours |
| Connectivity | 1 × DisplayPort, 3 × HDMI, 2 × USB |
| Audio Output | Stereo Mini Jack / eARC |
| Network | Wi-Fi, Bluetooth |
| Built-in Features | Integrated Controller, Speaker (10W × 2), Tizen OS, MagicINFO Support |
