Viewsonic-CDE9830
0- Category:Viewsonic Led
- Wireless presentation for enhanced efficiency
- Single USB-C cable for 65W power delivery
- 24/7 video playback for continuous communication
- Remote device management with myViewBoard Manager
- ProAV compatibility with Crestron, Extron, and AMX
- Portrait-oriented display for impactful brand signage
Specification
| Specification | Details |
|---|---|
| Panel Size | 98″ (Diagonal) |
| Panel Type / Technology | TFT LCD Module (ADS type) with DLED backlight |
| Display Area (mm) | 2158.848 (H) × 1214.352 (V) |
| Native Resolution | 3840 × 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Colors | 1.07 Billion (8-bit + FRC-) |
| Brightness | 500 nits (typical) |
| Contrast Ratio | 1200:1 (typical), 5000:1 (DCR) |
| Response Time | 8 ms |
| Viewing Angles | 178° H / 178° V |
| Backlight Life | 50,000 hours |
| Surface Treatment | Anti-Glare, 3H hardness, Haze 25% |
| Bezel Size (L/R/T/B) | 25/25/25/25 mm |
| Orientation | Landscape & Portrait |
| Processor | Quad-core ARM Cortex A55 |
| RAM | 4 GB |
| Storage | 32 GB |
| HDMI Inputs | 3 × HDMI 2.1 (up to 3840×2160 @60Hz; HDMI 1 supports ARC) |
| RS-232 Input | 1 × RS-232 |
| OPS Slot | 1 × OPS Slot |
| Wi-Fi Slot | 1 × Wi-Fi Slot |
| HDMI Output | 1 × HDMI 2.0 (3840×2160 @60Hz) |
| SPDIF Output | 1 × SPDIF |
| LAN (RJ45) | 1 × RJ45 |
| USB Type-A | USB 2.0 ×1; USB 3.0 ×1 (Smart USB) |
| USB Type-C | 1 × USB-C (DP1.2, PD 65W, USB2.0, 100M Ethernet) |
| Speakers | 10W × 2 |
| Embedded OS | Android 11 |
| Power Supply | 100–240 VAC ±10% |
| Power Consumption | ~190 W (typ.) / <0.5W (off) |
| Operating Temp. | 0°C to 40°C |
| Operating Humidity | 10%–90% RH |
| Operating Hours | 24/7 |
| Dimensions (W × H × D) | Physical: 2212.9 × 1268.4 × 79 mm |
| Packaging Dimensions | 2360 × 1425 × 280 mm |
| Net Weight | ~69.40 kg |
| Gross Weight | ~90.30 kg |
| Certifications / Regulations | cTUVus, FCC/ICES003, Energy Star 8.0, EPEAT, Mexico NOM, CE, CB, EAC, RCM, RoHS, Green BOM, WEEE, and more |
| Package Contents | Remote with batteries, Quick Start Guide, Power cables, HDMI cable, USB-C cable, Wall mount screws ×4, RS-232 adapter, Compliance statement |
