| Specification | Details |
|---|---|
| Product Type | IP Streaming Encoder / Decoder |
| Video Encoding | H.264 / H.265 |
| Video Resolution | Up to 1080p@60Hz |
| HDMI Input Resolution | Up to 4K@60Hz 4:4:4 |
| HDMI Output Resolution | Up to 1080p@60Hz 4:4:4 |
| Transmission Type | HDMI over IP |
| Network Requirement | 100Mbps or Higher Switch |
| Transmission Distance | Up to 180m over CAT5e |
| Streaming Mode | Unicast / Multicast |
| Video Wall Support | Matrix & Video Distribution |
| HDMI Loop Out | Supported |
| Audio De-embedding | Supported |
| Video Recording | Supported |
| Live Preview | Supported on GUI |
| Protocols Supported | RTSP, RTP, HTTP FLV, UDP, TCP |
| Control Signals | RS232, IR |
| PoE Support | IEEE 802.3at PoE |
| LAN Port | 1× RJ45 |
| HDMI Ports | 1× HDMI In / 1× HDMI Out |
| Audio Output | Analog Audio Out |
| Control Ports | RS232, IR |
| External Power Supply | 12V DC 1A |
| Power Consumption | Encoder: 5W Max / Decoder: 2W Max |
| Operating Temperature | -5°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 10%–90% |
| Dimensions | 150 × 25 × 100 mm |
| Weight | Approx. 355g |
AV-OVER-IP
MP-IP200E&D
- Supports H.264, H.265 encoding and decoding.
- Adopt advanced universal coding technology
- High-definition picture quality transmission over IP network.
- Support unicast and multicast switching
- Large-scale application under 100M network.
- Support various audio and video scheduling controls
- Rich interfaces, including RS232, IO, IR, network, etc.
- Dual power supply mode, standard DC interface and IEEE802.3 at PoE
