Crestron TSW-1070-MSMK-B-S

The Crestron TSW-1070-MSMK-B-S is a multisurface mount kit that lets a TSW-1070 or TSS-1070 series touch screen be flush-mounted to glass, granite, marble, wood paneling, plaster or other smooth, flat surfaces.

It attaches with a peel-and-stick adhesive rear housing, without screws, and includes a self-adhering plastic raceway that conceals cables running to the screen.

Specifications

Technical Overview

Housing: Plastic, black or white finish
Mounting: Peel-and-stick adhesive to glass or other flat, smooth surface
Raceway: Peel-and-stick plastic raceway, white (paintable), 0.77 in. W × 0.46 in. D (19.6 × 11.7 mm); includes 3 × 3 ft sections and fittings
Dimensions (without touch screen): 5.04 in. H (128 mm) × 8.63 in. W (219 mm) × 1.69 in. D (43 mm)
Dimensions (with touch screen): 5.87 in. H (149 mm) × 9.46 in. W (240 mm) × 2.28 in. D (58 mm)
Dimensions (with touch screen and light bar): 6.59 in. H (167 mm) × 10.95 in. W (278 mm) × 2.25 in. D (57 mm)
Weight: 5.3 oz (102 g) without touch screen, light bar or raceway

Compatible Products

Frequently Paired With

Crestron TSW-770
