QSC AcousticCoverage AC-S6T-BK

The QSC AcousticCoverage AC-S6T is a surface-mounted 6.5-inch 2-way loudspeaker with a 70/100V transformer, suited to a wide variety of audio/video conferencing reinforcement, voice paging and background-music applications.

A 6.5-inch polypropylene woofer and 1-inch aluminum dome tweeter in a UV-treated ABS enclosure deliver broad 130° conical coverage, supplied as a pair with a yoke mount system.

Specifications

Technical Overview

LF Transducer: 165mm (6.5 in) polypropylene woofer, 25mm (1 in) voice coil
HF Transducer: 25mm (1 in) aluminum dome tweeter, 25mm (1 in) voice coil
Effective Frequency Range: 60 Hz – 20 kHz (-10dB)
Rated Noise Power / Voltage: 30 W / 15.5 V (rms), IEC60268-1, 2 hours
Broad-Band Sensitivity: 86 dB SPL (on-axis, 2.83V, 1m)
Coverage Angle (-6dB): 130° conical (500 Hz–5 kHz)
Directivity Factor (Q) / Index: 6 / 8 dB
Maximum Continuous / Peak SPL: 101 dB / 107 dB
Rated Impedance: 8 Ω
Recommended Amplifier: 60 W
Transformer Taps: 70V: 30/15/7.5/3.7/1.9 W; 100V: 30/15/7.5/3.8 W; 8Ω bypass
Input Connector: 4-pole Euroblock, parallel output (loop-thru wiring)
Enclosure Material: UV-treated, high-impact ABS polymer
Grille / Yoke Material: Powder-coated steel (yoke has brass inserts)
Ingress Protection: IP-44, indoor use
Operating Temperature: -20° to 50°C (-4° to 122°F)
Net Weight: 3.8 kg (8.3 lb)
Product Dimensions: 303 x 215 x 197 mm (11.9 x 8.5 x 7.8 in)
Color: Black (RAL 9011) or White (RAL 9010), paintable
Included Accessories: Yoke mount system, Euroblock connector
