QSC TouchMix-30 Pro

The QSC TouchMix-30 Pro is a 32-input digital mixer with a 10-inch, 1024x600 multi-touch display, offering 24 mic/line inputs (20 XLR, 4 XLR combo), 6 line inputs and 2 stereo USB inputs for professional live sound applications.

Automatic gain-sharing microphone mixing across 24 channels (two instances), 6 simultaneous effects engines, 12-band anti-feedback filtering and 32x32-track direct-to-hard-drive recording — plus a 32x32 Core Audio DAW interface for macOS — make it a complete front-of-house solution.

Specifications

Technical Overview

Display: 254 mm (10 in) Diagonal, 1024x600, Color TFT, Capacitive Multi-Touch
Total Inputs: 32 (24 Mic/Line [20 XLR, 4 XLR Combo], 6 Line, 2 Stereo USB)
Input EQ: 4-Band Parametric with Hi/Low Shelving, Variable 24dB/Octave HPF/LPF
Input Dynamics: Gate, Compressor
Delay: Up to 100 msec
Automatic Mic Mixer: Gain-Sharing, 24 Channels, 2 Instances (Firmware v1.3+)
Total Outputs: 16 (2 XLR Main L/R, 14 XLR Aux)
Output EQ: 1/3-Octave GEQ, 6-Band Parametric EQ, Variable HPF/LPF
Anti-Feedback Filters: 12-Band
Output Dynamics: Compressor/Limiter
Multi-Track Recording: 32x32 Direct-to-Hard-Drive, Plus 32x32 Core Audio DAW Interface (macOS)
Effects: 6 Simultaneous Engines: Reverb, Echo, Delay, Chorus, Pitch Shift
RTA: 2x 1/3-Octave, Assignable
Wireless Control: TouchMix-30 Pro Control App (iOS/Android) via Wi-Fi
Third-Party Control Surfaces: Supported via Mackie Control Protocol (Firmware v2.0+)
