NovaStar DSP1000 Pro

The NovaStar DSP1000 Pro is a high-performance, all-in-one LED video processor and controller built for large-scale, high-resolution LED video walls, professional events, control rooms and digital signage installations. It combines video processing and LED display control in a single 1U rack-mount unit, configured and operated through NovaStar's control software and the Unico web interface.

On the input side, a single HDMI 2.0 port accepts up to 4096×2160 at 60Hz (8/10/12-bit, RGB/YCbCr 4:4:4 and 4:2:2, HDCP 1.4/2.2) with custom resolutions and frame rates up to 144Hz, alongside two HDMI 1.3 inputs (up to 1920×1080@60Hz) and a 3G-SDI input supporting SMPTE 259M/274M/296M/425M-A/425M-B with loop output and deinterlacing. On the output side, ten Gigabit Ethernet ports deliver up to 6.5 million pixels of loading capacity across a maximum canvas of 10,240 × 8,192 pixels, backed by two 10G optical fibre ports that can be configured for input, output, loop or backup duty over distances up to 10km (single-mode) or 300m (multi-mode).

Specifications

Technical Overview

Product Type: All-in-One LED Video Processor and Controller
HDMI 2.0 Input (x1): Max 4096×2160@60Hz; max width 8192px @60Hz, max height 8188px @60Hz; 8/10/12-bit; RGB/YCbCr 4:4:4, 4:2:2; HDCP 1.4/2.2; loop out; custom resolutions; embedded audio; up to 144Hz; no interlaced input
HDMI 1.3 Input (x2): Max 1920×1080@60Hz; max width/height 2048px; 8-bit; HDCP 1.4; custom resolutions; embedded audio; RGB/YCbCr 4:4:4, 4:2:2; no interlaced input
3G-SDI Input (x1): ST-424 (3G), ST-292 (HD), ST-259 (SD); SMPTE 259M/274M/296M/425M-A/425M-B; max 1920×1080@60Hz; 10-bit; loop output; deinterlacing; no input resolution/bit-depth settings
Ethernet Output Ports (x10): Max loading capacity 6.5 million pixels; max width 10,240px, max height 8,192px; 650,000 pixels per port @8-bit; up to 144Hz
Optical Fibre Ports (OPT 1/OPT 2): 2x 10G; OPT1 self-adaptive input/output, OPT2 output (copy/backup) or loop; input-output, input-loop and output modes; single-mode ≤10km, multi-mode ≤300m; optical modules sold separately
HDMI 1.3 Monitor Output (x1): Fixed 1920×1080@60Hz, for local monitoring
3D Connector (x1): For 3D emitter with compatible glasses; output capacity halved when 3D is active with Side-by-Side/Top-and-Bottom sources
Audio I/O: 1x 3.5mm input, 1x 3.5mm output; up to 48kHz sampling rate
Control Ethernet Ports (x2): 1 port for PC connection to the Unico web interface; 1 port for input/output cascading; link and data-activity status LEDs
USB: 1x USB 2.0 — firmware updates, device log and EDID file import/export via USB drive
RS232: 1x, 3-pin (RX, TX, G)
Genlock: 1x IN-LOOP; accepts bi-level and tri-level sync signals
Ambient Light Sensor: 1x connector, for automatic brightness adjustment
Control Software: NovaStar control software, Unico web interface

Key Features

What It Delivers

Integrated video processing and LED display control in one unit
4K HDMI 2.0 input up to 4096×2160@60Hz
10 Gigabit Ethernet output ports
Up to 6.5 million pixels loading capacity
Maximum output canvas of 10,240 × 8,192 pixels
Dual 10G optical fibre ports — configurable input, output, loop or backup
HDMI 1.3 and 3G-SDI video inputs
Image scaling and custom-resolution support
3D output connector for Side-by-Side/Top-and-Bottom sources
Audio input and output
USB 2.0, RS232, Genlock in/loop and ambient light sensor connectors
Controlled via NovaStar software and the Unico web interface
