- Sensor
- 1/1.8" 9.17MP CMOS
- Video Format
- 2160p: 59.94/50/29.97/25fps; 1080p: 59.94/50/29.97/25fps; 1080i: 59.94/50fps; 720p: 59.94/50fps
- Video Output Interface
- HDMI / Ethernet / 12G-SDI / 3G-SDI / USB 3.0
- Genlock
- Yes
- Optical Zoom
- 30x
- Digital Zoom
- 12x
- Horizontal Viewing Angle
- 63° (Wide) to 3.7° (Tele)
- Vertical Viewing Angle
- 35.4° (Wide) to 2.1° (Tele)
- Diagonal Viewing Angle
- 72.3° (Wide) to 4.2° (Tele)
- Aperture
- F1.6 ~ F4.8
- Focal Length
- 6.5mm ~ 202mm
- Shutter Speed
- 1/1 ~ 1/10,000 sec
- Minimum Object Distance
- 1.5m (Wide/Tele)
- Video S/N Ratio
- > 50dB
- Minimum Illumination
- 0.05 lux (F1.6, 50IRE, 30fps)
- Focus System
- Auto / Manual / Smart AF
- Gain Control
- Auto / Manual
- White Balance
- Auto / Manual
- Exposure Control
- Auto / Manual / Smart AE
- IQ Sync
- Yes
- WDR
- Yes
- 3D NR
- Yes
- Image Flip
- Yes
- Color Space
- Standard / BT.2020 / REC.709
- AR/VR Systems
- FreeD
- Tally Light
- Yes
- Panning Angle
- +170° ~ -170°
- Panning Speed
- 0.01° ~ 300°/sec
- Tilting Angle
- +90° ~ -30°
- Tilting Speed
- 0.01° ~ 300°/sec
- Preset Positions
- 256
- HDMI / 12G-SDI Output
- 2160p 59.94
- IP Stream
- NDI: HEVC(H.265) 4K59.94fps, H.264 640x360 29.97fps; RTSP: HEVC(H.265) 4K59.94fps, H.264 1080p59.94fps, H.264 640x360 29.97fps
- IP Compression
- H.264 / HEVC(H.265)
- USB Output
- H.264 4K30fps, MJPEG 1080p30
- USB Compression
- H.264 / MJPEG
- IP Protocol
- NDI High Bandwidth / NDI HX3 / NDI HX2 / RTSP / RTMP / RTMPS / MPEG-TS / SRT
- PoE
- PoE++ (IEEE802.3bt)
- Audio Input
- Line In / MIC In, 3.5mm phone jack x1
- Audio Output
- Ethernet / 12G-SDI / 3G-SDI / HDMI 2.0 / USB 3.0
- Audio Compression Format
- AAC / G.711 / PCM
- Control Interface
- RS-232 / RS-422 / Ethernet / USB
- Control Protocol
- VISCA / VISCA over IP / PELCO D / ONVIF / UVC
- Dimensions
- 9.2" x 7.4" x 7.4" (232 x 188 x 189 mm)
- Weight
- 6.6 lbs (3 kg)
- Power
- PoE++ (802.3bt) 27.5W or 12V DC 27W
- Warranty
- 5-Year Limited Warranty
