| Specification | Details |
|---|---|
| Display Size | 55-inch |
| Display Technology | LCD Video Wall |
| LCD Type | PVA |
| Resolution | Full HD 1920 × 1080 |
| Backlight | Direct LED |
| Brightness | 800 cd/m² (Typical) |
| Contrast Ratio | 4000:1 Typical |
| Aspect Ratio | 16:9 |
| White Point | 10,500 K |
| Color Calibration | Sense X Automatic Color & Brightness Calibration |
| Bit Depth | 10–12 Bit |
| Refresh Rate | 50/60 Hz |
| Viewing Angle | 178° / 178° |
| Response Time | < 8 ms |
| Cooling | Fan-less |
| Operation | 24/7 Continuous Use |
| Backlight Lifetime | 100,000 Hours |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10%–80% Non-condensing |
| Storage Temperature | -20°C to 65°C |
| Orientation | Landscape / Portrait |
| Mounting | UniSee Smart Mount |
| Bezel | Truly Bezel-less NoGap Technology |
| DisplayPort | 2× DP 1.2 Inputs, 1× DP 1.2 Output |
| HDMI | 2× HDMI 1.4 Inputs |
| Ethernet | 2× Ethernet Ports |
| USB | 2× USB (Power Only) |
| HDCP | Supported |
| AC Input Voltage | 100–240 VAC, 50–60 Hz |
| Power Consumption | 190W (Internal PSU) / 175W (External PSU) |
| Heat Dissipation | 650 BTU/h |
| Dimensions (Internal PSU) | 1213.5 × 683 × 102.4 mm |
| Dimensions (External PSU) | 1213.5 × 683 × 94.9 mm |
| Weight | 15 kg (LCM) / 17.4 kg LCD Net |
| Certifications | CE, FCC, UL, RoHS |
Barco
Barco UniSee (UNI‑8002)c
- Bezel-less design with NoGap technology at 800 cd/m²
- Mounting structure with automatic alignment for ensured precision
- Sense X automatic and continuous calibration
- Modular, future-proof platform
