| Model Name |
Samsung QMC 98″ Commercial Display |
| Model Number |
LH98QMCEBGCXZA |
| Series |
QMC Series |
| Screen Size |
98 Inch |
| Measured Screen Size |
97.5 Inch |
| Display Type |
Crystal UHD Digital Signage |
| Resolution |
3840 x 2160 (4K UHD) |
| Panel Type |
VA |
| Brightness (Typical) |
500 nit |
| Contrast Ratio |
5,500:1 |
| Dynamic Contrast |
Mega |
| Viewing Angle |
178° / 178° |
| Response Time |
8 ms |
| Color Gamut |
NTSC 72% |
| Glass Haze |
25% |
| Pixel Pitch |
0.562 x 0.562 mm |
| Active Display Area |
2158.85 x 1214.35 mm |
| Orientation Support |
Landscape / Portrait |
| Operation Time |
24/7 |
| Processor |
CA73 1.6GHz Quad-Core |
| Picture Engine |
Quantum Processor Lite 4K |
| Upscaling |
Intelligent UHD Upscaling |
| HDR Support |
Yes |
| Operating System |
Tizen 7.0 |
| Internal Storage |
16 GB (10 GB usable) |
| Internal Player |
MagicINFO S10 / SSSP 10.0 |
| HDMI In |
3 x HDMI 2.0 |
| DisplayPort In |
1 x DP 1.2 |
| USB Ports |
2 x USB 2.0 |
| Audio Output |
Stereo Mini Jack |
| Speaker |
10W x 2CH |
| RJ45 LAN |
Yes |
| RS232 Control |
In / Out |
| IR Sensor |
Center IR |
| Wi-Fi |
Yes (2.4 / 5GHz Dual Band) |
| Bluetooth |
Yes |
| Ambient Sensor |
Yes |
| Temperature Sensor |
Yes |
| Auto Source Switching |
Yes |
| SmartView+ |
Yes |
| Smart Calibration |
Yes |
| Workspace |
Microsoft 365 / VMware / RDP |
| Power Supply |
AC 100-240V, 50/60Hz |
| Power Consumption (Typical) |
197 W |
| Power Consumption (Max) |
363 W |
| Sleep Mode |
< 0.5 W |
| Dimensions (Set) |
2192 x 1249.7 x 48.1 mm |
| Package Dimensions |
2370 x 1397 x 228 mm |
| Net Weight |
56.3 kg |
| Package Weight |
77.2 kg |
| VESA Mount |
600 x 400 mm |
| Bezel Width |
14.8 mm (Even) |
| Bezel Color |
Slate Black |
| IP Rating |
IP5X Dust Resistant |
| EMC Class |
Class A |
| Safety Compliance |
60950-1 / 62368-1 |
| Energy Certification |
ENERGY STAR 8.0 / EPEAT |
