Crestron IV-SAM-VX2-S

The Crestron IV-SAM-VX2-S Automate VX System Series 2 switches between 1 Beyond cameras automatically based on the active speaking participant, with AutoFraming and reframing through Visual AI.

It supports up to three 3G-SDI camera inputs and five NDI|HX inputs plus a USB camera, records to 316 GB of internal SSD storage, streams to any RTMP server and provides a REST API for third-party control.

Specifications

Technical Overview

Camera Inputs: 3 × 3G-SDI (12-bit); up to 5 × NDI|HX; USB Type-A 3.2 or USB Type-C 3.2 camera (one at a time)
Outputs: HD-SDI (SDI to USB-A converter included); NDI|HX; virtual webcam; HDMI 2.0b
Recording: MP4 (H.264, up to 10 Mbps) or MOV; 316 GB internal SSD
Streaming: RTMP to any RTMP server
Camera Control: Crestron 1 Beyond PTZ and tracking cameras over IP
System Control: REST API over TCP for third-party control
Audio Inputs: Dante networking audio (licence not included); USB; line-level and mic 3.5 mm inputs
Ethernet: 3 × RJ-45, 10/100/1000/2500 Mbps
Desktop Output: HDMI and DisplayPort 1.4a for configuration via monitor
Configuration: Browser-based with secure login and user administration
